BATTPAT

Battery Powered PAT Tester

Manufactured by Tele-Products Ltd

11, Glaisdale Road

Northminster Business Park

York, YO26 6QT


MemoryPAT & MemoryPAT-Blu

Battery Powered Portable Appliance Tester with Display & Memory

Test results downloadable to PC & Android device


BattPAT testing kettle

Testing a kettle (Class I)

The kettle is plugged into the BattPAT PAT tester.

The test lead is connected to the element.

The power switch on the kettle is moved to the on position.

The Class I (metal) button is pressed to see the results.

Testing a charger (Class II)

The charger is plugged into the BattPAT PAT tester.

The test lead is connected to the connector.

The Class II (metal) button is pressed to see the results.

BattPAT testing charger

Testing an extension lead

The extension lead is plugged into the BattPAT PAT tester.

The short IEC lead is plugged into the extension lead and the power socket on the BattPAT.

The Power Cord button is pressed to see the results.

BattPAT testing extension lead

Testing a 100V extension lead

The 110 V extension lead is plugged into the BattPAT PAT tester, using a 110V adaptor.

The 110V to IEC adaptor is plugged into the 110V extension lead and the power socket on the BattPAT.

The Power Cord button is pressed to see the results.

(The 110V adaptor and the 110V to IEC adaptor need to be purchased separately.)

BattPAT testing 110V extension lead

BattPAT test examples
